· 16 high-speed, auto-sensing 10/100/1000 Mbps Ethernet connections
· Integrates 10, 100, & 1000 Mbps devices within a network
· Silently delivers up to 2000 Mbps on each port


Network Ports
· 16 RJ-45 auto-sensing 10/100/1000 Mbps UTP ports

Forwarding Mode
· Store-and-forward

Performance
· Bandwidth: 32 Gbps (non-blocking)
· Forward rate (10 Mbps port): 14,800 packets/sec
· Forward rate (100 Mbps port): 148,000 packets/sec
· Forward rate (1000 Mbps port): 1,488,000 packets/sec
· Latency (100 to 100 Mbps): 40 ? (max)
· Latency (1000 to 1000 Mbps): 10 ? (max)
· Queue buffer memory: 512 Kbytes per port
· MAC address database: 8,000
· Acoustic noise: 0 dB
· Heat dissipation: 38.8 Btu/hr
· Mean time between failures (MTBF): 393,000 hours (45 years)

AC Power
· 18W max and 12V @ 1.5A DC input

Status LEDs
· Power, activity and link indicators for each port
· Link and speed indicators built into each RJ-45 port

Physical Specifications
· Dimensions: (w x d x h) 285 x 103 x 27 mm (11.22 x 4.06 x 1.06 in)
· Weight: 0.99 kg (2.2 lb)

Environmental Specifications
· Operating temperature: 0° to 50° C (32° to 122° F)
· Operating humidity: 10% to 90% non-condensing

Safety Agency Approvals
· CE mark, commercial
· UL listed (UL 1950)
· C-Tick

Electromagnetic Compliance
· CE mark, commercial
· FCC Part 15 Class A
· EN 55 022 (CISPR 22)
· Class A VCCI
· Class A C-Tick

Standards Compliance
· IEEE 802.3i 10BASE-T Ethernet
· IEEE 802.3u 100BASE-TX Fast Ethernet
· IEEE 802.3ab 1000BASE-T Gigabit Ethernet
· Honors 802.1p priority tags
· Honors DSCP priority tags

Package Contents
· ProSafe 6-port Gigabit Desktop Switch (GS116)
· Wall-mount kit
· AC adapter
· Installation guide
· Warranty/support information card
