Features

· Patented ?92x32mm PWM upside-down fan offers a perfect balance between airflow and noise.
· Aluminum heatsink dissipates heat effectively.
· Mirror polished base provides perfect contact between CPU and heatsink.


Technical Spec

Application For
· AMD Socket 89W
· FM1/AM3+/AM3/AM2+/AM2/940/939/754

Overall Dimension
· 95X105X76mm

Fan Dimension
· ?92X32mm

Net Weight
· 307g

Bearing Type
· Hydro Bearing

Rated Voltage
· 12VDC

Operating Voltage
· 10.8~13.2VDC

Started Voltage
· 7VDC

Rated Current
· 0.20±10%A

Power Input
· 2.4W

Fan Speed
· 2200±10%RPM

Max. Air Flow
· 40.9CFM

Noise
· 25dB(A)
