Intel Core i3-12100 3.30GHz/4.30GHz (P), 12MB, 4PC/0EC/8T, 60W/89W, Includes Fan, HD730 Graphics (1700)
Alder Lake 10nm, LGA1700, 12MB SmartCache, Includes Fan, HD730 Graphics
Availability
13 Available
Warranty
3 Year RTB Warranty
TasTech Product ID
523428
Part/Model Number
· BX8071512100
Other Links
· This Category
· All Intel Products
Intel® Core® i3-12100 Processor
12M Cache, up to 4.30 GHz
CPU Specifications
· Total Cores 4
· # of Performance-cores 4
· # of Efficient-cores 0
· Total Threads 8
· Max Turbo Frequency 4.30 GHz
· Performance-core Max Turbo Frequency 4.30 GHz
· Performance-core Base Frequency 3.30 GHz
· Cache 12 MB Intel® Smart Cache
· Total L2 Cache 5 MB
· Processor Base Power 60 W
· Maximum Turbo Power 89 W
Processor Graphics
· Processor Graphics ‡ Intel® UHD Graphics 730
· Graphics Base Frequency 300 MHz
· Graphics Max Dynamic Frequency 1.40 GHz
· Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
· Execution Units 24
· Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz
· Max Resolution (DP)‡ 7680 x 4320 @ 60Hz
· Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
· DirectX* Support 12
· OpenGL* Support 4.5
· Multi-Format Codec Engines 1
· Intel® Quick Sync Video Yes
· Intel® Clear Video HD Technology Yes
· # of Displays Supported ‡ 4
· Device ID 0x4692
· OpenCL* Support 2.1
12M Cache, up to 4.30 GHz
CPU Specifications
· Total Cores 4
· # of Performance-cores 4
· # of Efficient-cores 0
· Total Threads 8
· Max Turbo Frequency 4.30 GHz
· Performance-core Max Turbo Frequency 4.30 GHz
· Performance-core Base Frequency 3.30 GHz
· Cache 12 MB Intel® Smart Cache
· Total L2 Cache 5 MB
· Processor Base Power 60 W
· Maximum Turbo Power 89 W
Processor Graphics
· Processor Graphics ‡ Intel® UHD Graphics 730
· Graphics Base Frequency 300 MHz
· Graphics Max Dynamic Frequency 1.40 GHz
· Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
· Execution Units 24
· Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz
· Max Resolution (DP)‡ 7680 x 4320 @ 60Hz
· Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
· DirectX* Support 12
· OpenGL* Support 4.5
· Multi-Format Codec Engines 1
· Intel® Quick Sync Video Yes
· Intel® Clear Video HD Technology Yes
· # of Displays Supported ‡ 4
· Device ID 0x4692
· OpenCL* Support 2.1
