Intel® Core® i5-12400 Processor
18M Cache, up to 4.40 GHz

CPU Specifications

· Total Cores 6
· # of Performance-cores 6
· # of Efficient-cores 0
· Total Threads 12
· Max Turbo Frequency 4.40 GHz
· Performance-core Max Turbo Frequency 4.40 GHz
· Performance-core Base Frequency 2.50 GHz
· Cache 18 MB Intel® Smart Cache
· Total L2 Cache 7.5 MB
· Processor Base Power 65 W
· Maximum Turbo Power 117 W

Processor Graphics

· Processor Graphics ‡ Intel® UHD Graphics 730
· Graphics Base Frequency 300 MHz
· Graphics Max Dynamic Frequency 1.45 GHz
· Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
· Execution Units 24
· Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz
· Max Resolution (DP)‡ 7680 x 4320 @ 60Hz
· Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
· DirectX* Support 12
· OpenGL* Support 4.5
· Multi-Format Codec Engines 1
· Intel® Quick Sync Video Yes
· Intel® Clear Video HD Technology Yes
· # of Displays Supported ‡ 4
· Device ID 0x4692 / 0x4682
· OpenCL* Support 2.1
